产品简介 Product Introduction
应用在纺织服装行业、家纺行业的洗水唛组合固定。有效解决工业大小洗水唛在智能化、自动化设备车缝应用的不足，人
工多种标签组合缝制操作中容易出错，速度慢等多种问题。联合缝纫机，超声波技术实现全自动缝合标签技术。
It is used in the combination and fixation of washing marks in textile and garment industry and home textile
industry.It can effectively solve the shortage of industrial washing marks in intelligent and automatic equipment
sewing,and many problems such as easy error and slow speed in manual muti label combination sewing.
Combined sewing machine and utrasonic technology to realize full-automatic sewing label technology.
效益 Capacity
| 设施 Facilities |
工人 Worker |
标准工时 Standard working time |
生产力 Production/H |
日产量 Yield/Day |
|---|---|---|---|---|
| 手工作业方式 Manual work |
一人工 One person one machine |
9S/PCS | 360 | 2880 |
| 全自动洗水唛粘合机 Automatic Care Label Welding Machine |
一人三机 One operator three machines |
3S/PCS | 1200 | 23040 |
主要技术规格 Main Technical Specification
电压
Voltage
AC220V
进气电压
Intake pressure
0.5-0.7MPa
吸气电压
Suction pressure
0.2MPa
每组成品标签数量
Number of finished product labels per group
2-6pcs
标签长度使用范围（mm）
Label length usage range(mm)
45-100
标签宽度使用范围（mm）
Label width usage range(mm)
34/45/50
仓位容量
Bin capacity
300/pcs
运行速度
Running speed
3-3.5s/pcs
缝合类型
Stitch Type
超声波(ultrasonic)
PLC控制品牌
PLC control brand
松下(Panasonic)
电机品牌
Motor brand
雷赛(leisai)
气缸品牌
Cylinder brand
亚德客(AirTAC)
电气品牌
Electrical brand
欧姆龙(OMRON)
外形尺寸(mm)
Overall dimension(mm)
1000(L)*700(W)*1650(H)
机器可根据客户需求定做 Machines can be customized according to customer needs
